Key Specifications

System Type

5'' 2-Way Passive Line Array Module

Power Capacity

120W (Continuous) / 240W (Program)

Nominal Impedance

8 Ω

Sensitivity (1W/1M)

95 dB

Audio Performance

Frequency Response

90 Hz – 20 kHz (-10dB)

Maximum SPL @ 1m

115.5 dB Max

Dispersion (-6dB)

100° Horizontal / 12° Vertical

Crossover Frequency

2.0 kHz (Passive)

Transducers & Hardware

LF Drivers

2 x 5'' Woofer (1.18'' Voice Coil)

HF Driver

1 x 1'' Tweeter (1'' Voice Coil)

Rigging System

Adjustable Splay (0° to 12° in 1.5° increments)

Physical Specs

Enclosure Material

Polypropylene (with Steel Grille)

Dimensions (WxHxD)

430 x 161 x 304 mm

Net Weight

8 kg (17.63 lbs)
