Key Specifications

Active/Passive

Passive

Number of Included Speakers

2

Speaker Configuration

Full-Range

Power Handling

For 2 Hours:
20 W RMS
40 W Program
80 W Peak

Constant Voltage / Transformer Taps

70 V: 1 / 2 / 4 / 8 / 16 W or 16 Ohms Bypass
100 V: 2 / 4 / 8 / 16 W or 16 Ohms Bypass

Impedance

16 Ohms (Transformer Bypassed)

Full-Range Driver

1x 2.25" / 5.71 cm Cone

Frequency Range

83 Hz to 19 kHz (-10 dB)

Color

Black, White

Speaker

Active/Passive

Passive

Number of Included Speakers

2

Speaker Configuration

Full-Range

Power Handling

For 2 Hours:
20 W RMS
40 W Program
80 W Peak

Constant Voltage / Transformer Taps

70 V: 1 / 2 / 4 / 8 / 16 W or 16 Ohms Bypass
100 V: 2 / 4 / 8 / 16 W or 16 Ohms Bypass

Impedance

16 Ohms (Transformer Bypassed)

Transformer Wattage

16 W

Enclosure Type

Sealed

Shielded

No

Drivers

Full-Range Driver

1x 2.25" / 5.71 cm Cone

Performance

Frequency Range

83 Hz to 19 kHz (-10 dB)

Frequency Response

95 Hz to 16 kHz (-3 dB)

Maximum SPL

99 dB (Continuous)
105 dB (Peak)

Sensitivity

86 dB

Coverage Angle

150° (Conical)

Recommended High-Pass Filter

85 Hz, 24 dB/Octave

Connectivity

Inputs/Outputs

1x Block 6-Pin Speaker Input/Thru

Maximum Wire Gauge

14 AWG / 2.5 mm

Physical

Environmental Resistance

No

Operating Conditions

32 to 122°F / 0 to 50°C

Color

Black

Cutout Size

6.3 x 6.3" / 16 x 16 cm

Mount Surface Thickness

Up to 1.5" / 3.8 cm

Construction Material

Plastic, Steel

Dimensions

7.2 x 5.2" / 18.3 x 13.2 cm

Weight

3.6 lb / 1.6 kg (Each Speaker, with Grille)
