Key Specifications

Form Factor/Type

Tabletop (Rack-Mountable with Optional Hardware)

Number of Mixer Inputs

3

Number of Amplifier Channels

1

Load Impedance/Voltage Support

100 / 70 V

Power Rating per Channel

1× 90 W at 100/70 V

Amplifier Class

Class-D

Performance

Protections

Short Circuit, Thermal

Frequency Response

60 Hz to 20 kHz +0/-3 dB (at 1 W)

THD/Distortion

≤ 0.3% THD+N (at Rated Power)

Crosstalk

≤ -60 dBu (Below Rated Power, 1 kHz)

Signal Processing

AD/DA Conversion

24-Bit / 48 kHz

DSP

Yes

Audio Delay

No

EQ & Filters

2-Band EQ

Dynamics

No

Connectivity

Analog Audio I/O

1× Combo XLR-1/4" TRS Balanced/Unbalanced Line/Mic Input
1× 1/8" (3.5 mm) TRS Unbalanced Aux Input
1× Block 4-Pin Page
2× Stereo 2RCA Unbalanced Line
1× Block 3-Pin Speaker Output
1× Stereo 2RCA Aux Output

Digital Audio I/O

No

Network I/O

No

Other I/O

1× Block 4-Pin Remote Input
1× Block 2-Pin Mute

USB I/O

No

Phantom Power

No

Wireless

No

Power

Input Power

100 to 240 VAC, 60 / 50 Hz

AC Power Connector

1× IEC

Current Consumption

7.6 to 13.9 A (Max)

Power Consumption

15 W (Standby)
200 W (Max)

Physical

Display

Single-LED Indicators Only

Rackmount Size

1 U (1/2-Rack)

Cooling

Convection

Dimensions

12.2 × 8.4 × 1.8" (309.9 × 213.4 × 45.7 mm)

Weight

7 lb (3.2 kg)

Packaging Info

Package Weight

9 lb

Box Dimensions (L×W×H)

18.1 × 11.1 × 4.1"
