Key Specifications

Form Factor/Type

Rackmount

Number of Amplifier Channels

2

Load Impedance/Voltage Support

100 / 70 V

Power Rating per Channel

2× 120 W

Performance

Protections

Overvoltage, Short Circuit, Thermal, Undervoltage

Frequency Response

55 Hz to 20 kHz +0/-3 dB (at 1 W)

THD/Distortion

≤ 0.3% THD+N (at Rated Power)

Crosstalk

≤ -58 dBu (Below Rated Power, 1 kHz)

Signal Processing

AD/DA Conversion

24-Bit / 48 kHz

DSP

Yes

Audio Delay

No

EQ & Filters

2-Band EQ

Dynamics

Ducking/Muting

Connectivity

Analog Audio I/O

2× Stereo 2RCA Unbalanced Input
2× Block 5-Pin Balanced Input
1× Block 4-Pin Line/Page/Mic Input
1× Stereo 2RCA Aux Output
2× Block 2-Pin Speaker

Digital Audio I/O

No

Network I/O

No

Other I/O

1× Block 2-Pin Mute Input
2× Block 4-Pin Remote Input

USB I/O

1× USB-B (Service/Update)

Phantom Power

No

Wireless

No

Power

Input Power

100 to 240 VAC, 60 / 50 Hz

AC Power Connector

1× IEC

Current Consumption

12.6 A (Max)

Power Consumption

26 W (Standby)
300 W (Max)

Physical

Display

Single-LED Indicators Only

Rackmount Size

1 U

Cooling

1× Fan

Dimensions

19 × 12.8 × 1.8" / 482.6 × 325.1 × 45.7 mm

Weight

9 lb / 4.1 kg

Packaging Info

Package Weight

12.71 lb

Box Dimensions (L×W×H)

22.8 × 15.5 × 5.2"
