Key Specifications

Form Factor / Type

Rackmount

Number of Amplifier Channels

2

Load Impedance / Voltage Support

2 / 4 / 8 / 16 Ohms
25 / 70 / 100 V

Power Rating per Channel

2x 500 W Peak at 2/4 Ohms
2x 250 W at 8 Ohms
2x 320 W Peak at 25 V

Channel Bridging & Power Sharing

1x 1000 W Peak Bridged at 4 Ohms
1x 500 W Bridged at 8 Ohms
1x 1000 W Peak Bridged at 70/100 V

Amplifier Class

Class-D

Performance

Protections

DC Fault, Overload, Short Circuit, Thermal, Undervoltage

Frequency Response

20 Hz to 20 kHz ±0.5 dB (8 Ohms, -3 dB Below Rated Power)

SNR / Noise

>108 dBA SNR (at 8 Ohms)

THD / Distortion

≤ 0.05% THD+N

Signal Processing

DSP

Yes

Audio Delay

No

Dynamics

Compressor, Limiter

Connectivity

Analog Audio I/O

2x Block 6-Pin Balanced Line/Mic Input
4x RCA Unbalanced Line Input
1x Block 4-Pin Speaker Output

Digital Audio I/O

1x TOSLINK Optical S/PDIF Input
1x TOSLINK Optical S/PDIF Output

Network I/O

1x RJ45 Ethernet

Other I/O

1x Block 8-Pin GPIO

USB I/O

No

Phantom Power

No

Wireless

Wi-Fi

Power

Input Power

100 to 240 VAC, 50 / 60 Hz

AC Power Connector

1x IEC 15 A / NEMA 5-15

Power Consumption

0.5 W (Standby)
550 W (Typical)

Physical

Display

Single-LED Indicators Only

Rackmount Size

2 U

Cooling

1x Fan (Variable Speed)

Operating Conditions

32 to 104°F / 0 to 40°C

Dimensions

17.3 x 13.1 x 3.5" / 43.9 x 33.3 x 8.9 cm

Weight

13 lb / 5.9 kg

Packaging Information

Package Weight

17.605 lb

Box Dimensions (L × W × H)

22.7 x 17.8 x 9.5"
