Key Specifications

Inputs

• Mic/Line XLR Inputs: Balanced XLR, +48V Phantom Power
• Mic/Line Preamp: Fully Recallable
• Input Sensitivity: -60 to +15 dBu
• Analog Gain: +5 to +60 dB, 1 dB Steps
• Pad: -20 dB Active Pad
• Maximum Input Level: +30 dBu (Pad In)
• Input Impedance: >4 kOhms (Pad Out), >10 kOhms (Pad In)
• Mic EIN: -127 dB with 15-Ohm Source
• Phantom Power Indication: Per Socket, Internal or External Phantom Power Sensing, Triggered at 24 V

Outputs

• Analog XLR Outputs: Balanced, Relay Protected
• Output Impedance: <75 Ohms
• Nominal Output: +4 dBu = 0 dB Meter Reading
• Maximum Output Level: +21 dBu
• Residual Output Noise: -95 dBu (Muted, 22 Hz to 22 kHz)

Temperature

• Operating Temperature Range: 32 to 104°F / 0 to 40°C

Power

• Mains Voltage Operating Range: 100 to 240 VAC, 50/60 Hz
• Mains Power Consumption: 80 W Maximum

Dimensions

• 18.9 x 10.0 x 9.0" / 48.0 x 25.4 x 22.8 cm

Weight

• 17.6 lb / 8.0 kg

Packaging Info

• Package Weight: 22.595 lb
• Box Dimensions (L x W x H): 22 x 14.4 x 13.7"
