Key Specifications

Number of Simultaneous Recording Tracks

2 (STEREO mode), 4 (4CH mode), 2 (MTR mode)

Recording Time (4 GB SDHC)

Approx. 380 minutes (WAV 44.1 kHz / 16-bit stereo track)
Approx. 68 hours (MP3 44.1 kHz / 128 kbps stereo track)
* Recording times are approximations. Actual times may differ according to recording conditions.

Maximum File Size of Simultaneous Recording

2 GB

Projects

1000/card

Locate Function

Hours / Minutes / Seconds / Milliseconds

Other Functions

Punch-in/out, Bounce, A-B repeat

Effects Modules

2

STEREO / 4CH Mode

LO CUT, COMP/LIMITER

MTR Mode

PRE AMP module, EFX module

Types

53

Patches

60

Tuners

Chromatic, Guitar, Bass, Open A/D/E/G, DADGAD

Metronome Sound Sources

5

Variable Beat

1/4 – 8/4, 6/8, unaccentuated

Tempo

40.0 – 250.0 BPM

A/D Conversion

24-bit × 128 oversampling

D/A Conversion

24-bit × 128 oversampling

Recording Media

SD card (16 MB – 2 GB), SDHC card (4 GB – 32 GB)

Display

128 × 64 dots Full-dot backlit LCD

Data Type - WAV Format (Record/Play)

Quantization: 16- / 24-bit
Sampling Frequency: 44.1 / 48 / 96 kHz

Data Type - MP3 Format (Recording)

Bit Rate: 32, 40, 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 kbps, VBR
Sampling Frequency: 44.1 / 48 kHz

Input [1] [2]

XLR (balanced input) / standard phone (unbalanced input) combo jack

Input Impedance

(Using balanced input) 3 kΩ or more, pin 2 hot
(Using unbalanced input) 470 kΩ or more

Input Gain

(Using balanced input) −16 dB to +43 dB
(Using unbalanced input) -30 dB to +32 dB

Built-In Stereo Mic

Unidirectional condenser microphone
Sensitivity: -45 dB/1 Pa at 1 kHz
Input Gain: -16 dB to +51 dB
Maximum Sound Pressure Input: 140 dB SPL

External Mic

Mini stereo phone jack
Input Impedance: 2 kΩ or more
Input Gain: -16 dB to +51 dB

Line/Phone

LINE Output load impedance: 10 kΩ or more
LINE rated output level: -10 dBu
PHONE: 20 mW + 20 mW (into 32Ω load)

Monaural Speaker

400 mW 8 Ω

Phantom Power

48V, 24V, OFF

USB

USB 2.0 High Speed Mass Storage Class operation, Audio interface operation
(USB functions can be operated by USB bus power)

Power Requirements

DC 5V 1A AC from AC adapter (ZOOM AD-14), 2 × AA batteries

Batteries

IEC R6 (size AA) × 2

Continuous Recording Time

STEREO mode:
Using built-in mics at 44.1 kHz/16-bit without headphones connected
About 5.5 hours using alkaline batteries or about 7.5 hours using NiMH (2500mAh) batteries

STAMINA mode:
Using built-in mics at 44.1 kHz/16-bit without headphones connected
About 8 hours using alkaline batteries or about 10.5 hours using NiMH (2500mAh) batteries

Dimensions

73 (W) × 157.2 (D) × 37 (H) mm

Weight

294 g

Notes

* 0 dBm = 0.755 Vrms
* Design and specifications subject to change without notice.
