Key Specifications

Rated Output Power

150W (1 kHz, 4 ohm, 1% THD)

Rated Input Level (@ 1 kHz)

38.8mV RMS

Total Harmonic Distortion (@ 1 dB below rated output, 1 kHz typical)

0.6%

Signal To Noise Ratio

1W/62dB

Signal Gain Speaker Output

24.5V

Signal Gain to Direct Out and Send Jack

Direct Out: 7.6V; Send Out: 900mV

Bass Control

50 Hz

Mid Control

700 Hz

Treble Control

10 kHz

Seven-Band Graphic EQ Frequencies

63Hz, 125Hz, 250Hz, 500Hz, 1.25kHz, 2.5kHz, 5kHz

Dimensions

23.6" × 21.5" × 13.89" / 599mm × 545mm × 353mm (without casters)

Weight

57.8lb / 26.2kg
