Key Specifications

Rated Output Power

500 watts Peak / 250 watts RMS

Rated Input Level

77.46mV RMS (@ 1kHz)

Total Harmonic Distortion

0.54% (@ 1dB below rated output, 1kHz typical)

Signal To Noise Ratio

1W/49.3dBu (1Wrms @ 1kHz)

Signal Gain Speaker Output

37.1Vrms

Signal Gain to Direct Out

4.2Vrms

Bass Control

70Hz

Midrange Control

700Hz

Treble Control

5kHz

Shape Control

100Hz - 900Hz

Dimensions

19.6" × 12" × 20.27" / 498mm × 305mm × 515mm

Weight

34.39lb / 15.6kg
