Key Specifications

Number of Headphone Channels

6-Channel

Headphone Output Power

Up to 500 mW

Audio I/O

1/4" (Headphone), XLR / 1/4" (I/O)

Form Factor

Rackmount

Headphone Amplifier

Number of Headphone Channels

6-Channel

Headphone Output Power

500 mW into 32 Ohms (Max)
150 mW into 8 Ohms (Max)
150 mW into 600 Ohms (Max)

Connectivity

Analog Audio I/O

18x 1/4" TRS Unbalanced Headphone Output
2x XLR 3-Pin Balanced Input
9x 1/4" TRS Balanced Input
2x XLR 3-Pin Balanced Output
2x 1/4" TRS Balanced Output

Performance

Gain / Trim Range

22 dB

Maximum Input Level

+21 dBu

Dynamic Range

> 101 dB

Impedance

Outputs: < 12 Ohms
Line Inputs: 40 Kilohms
Aux Inputs: 15 Kilohms
Direct Inputs: 10 Kilohms

THD+N

< 0.1%

SNR

≥ 90 dB

Power

AC Input Power

105 to 125 VAC, 60 Hz

Physical

Rackmount Size

1 U

Dimensions (W × D × H)

19 x 7.5 x 1.75" / 483 x 190 x 45 mm

Weight

5.3 lb / 2.4 kg

Packaging Info

Package Weight

6.7 lb

Box Dimensions (L × W × H)

21.1 x 10.5 x 3.6"
