Key Specifications

Product / Accessory Type

Audio Signal Processor / Preamplification Equipment

Maximum Input Signal Level

+20 dBu

Frequency Response

10 Hz to 40,000 Hz (±1 dB)

Total Harmonic Distortion (THD)

< 0.010% (Typical)

Connectivity & Power Specifications

Analog Audio Inputs

XLR, 1/4" (6.3 mm) TRS / TS Inputs

Analog Audio Outputs

1/4" (6.3 mm) TRS / TS Outputs

Power Requirements

120 VAC, 60 Hz Internal / External Power Supply

Dimensions & Weight Specifications

Product Dimensions (L×W×H)

165.00 mm x 150.00 mm x 44.50 mm (6.50" x 5.90" x 1.75")

Product Net Weight

1.14 kg (2.50 lbs)
