Key Specifications

Product / Accessory Type

6-Channel Multi-Channel Headphone Amplifier & Distribution System

Form Factor & Enclosure Material

1U Rackmountable Metal Cabinet (Painted Surface Finish)

Audio Performance & Power Output

Power Output per Channel

6x 125 mW

Frequency Response

20 Hz to 20,000 Hz

Minimum Connected Headphone Impedance

8 Ohms

Input Impedance

13 kOhms

Connectivity & Channel Capacity Specifications

Total Inputs

8 Inputs: 1x Main Stereo Input, 1x Direct Stereo Input, 6x Aux Stereo Inputs

Input Connector Types

XLR, 1/4" (6.3 mm) TRS Jacks

Headphone Outputs

18 Total Output Connectors (6 Channels with 3x 1/4" / 6.3 mm TRS Jacks per Channel)

Line Outputs

Main Output (Stereo, Balanced) via XLR and 1/4" (6.3 mm) Jacks

Controls & Visual Indicators

Front Panel Controls

Power Switch, Main Input Level Control, 6x Headphone Level Controls, 6x Input Mix Main/Aux Controls, 6x Mono Switches, 6x Mute L&R Switches

Visual Status Indicators

Power LED, 8-Segment LED Main Input / Direct In Level Meter, 6x 4-Segment LED Channel Level Meters, 6x Mono Status LEDs, 6x Mute L&R Status LEDs

Power Specifications & Included Accessories

Operating AC Mains Voltage

Switchable 110 to 120 VAC, 50 / 60 Hz or 220 to 240 VAC, 50 / 60 Hz

Power Supply Connector

Standard IEC Power Inlet Connector

Included Accessories

AC Power Cord

Dimensions & Weight Specifications

Product Dimensions (W×H×D)

483.11 mm x 43.94 mm x 216.92 mm (19.02" x 1.73" x 8.54")

Product Net Weight

3.00 kg (6.61 lbs)
