Key Specifications

Inputs/Outputs

System Connection

PCIe 4.0 x4

Video Inputs

1x HDMI (1.4b) Female

Video Outputs

1x HDMI (1.4b) Female

Simultaneous Multi-Input Support

Not Specified by Manufacturer

Format Support

Input Video Format

• HDMI (8/10-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV): 720p at 50/59.94/60 fps, 1080p 23.98/24/25/29.97/50/59.94/60 fps, 1080i 50/59.94/60 fps, UHD 4K 23.98/24/25/29.97/30 fps
• SDI: 576i / 625 lines at 50 fps, 480i / 525 lines 59.94 fps

Input Audio Format

Analog: 48 kHz / 24-Bit

Output Video Format

• HDMI (8/10-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV): 720p at 50/59.94/60 fps, 1080p 23.98/24/25/29.97/30/50/59.94/60 fps, 1080i 50/59.94/60 fps, UHD 4K 23.98/24/25/29.97/30 fps
• SDI: 576i / 625 lines at 50 fps, 480i / 525 lines 59.94 fps

Output Audio Format

Analog: 48 kHz / 24-Bit

Standards

HDR Support

Not Specified by Manufacturer

Hardware

OS Compatibility

Windows 8.1, Windows 10, macOS 10.14 or Later, Linux

Power

Power Consumption

Device: 17 W

Environmental

Operating Temperature

32 to 104°F / 0 to 40°C

Storage Temperature

-4 to 113°F / -20 to 45°C

General

Certifications

C-Tick, CE, FCC

Dimensions

3.42" / 86.87 mm

Weight

0.22 lb / 0.1 kg

Packaging Info

Package Weight

0.75 lb

Box Dimensions (L x W x H)

5.6 x 5.45 x 2.15"
