Key Specifications

Power Source

PoE (IEEE802.3af) or PoE+ (IEEE802.3at)

Amplifier Rating

8 W (PoE) / 15 W (PoE+)

Network Interface

100BASE-TX, RJ45 connector

Acoustic Performance

Driver Unit

16 cm (6.3") Full-range cone-type

Frequency Response

60 Hz – 20,000 Hz

Max SPL

103 dB (at 15W output)

Sensitivity

94 dB (1 W, 1 m)

Connectivity & Integration

Audio Protocol

SIP (RFC3261), ONVIF Profile S

Remote I/O

1 Control Input / 1 Control Output

Internal Memory

Supports up to 20 audio files (WAV/MP3)

Physical Specs

Mounting Hole

φ200 mm (7.87")

Finish

Steel plate, White (RAL 9010 equivalent)

Weight

900 g (1.98 lbs)
