Key Specifications

Image Sensor

1/1.8" CMOS

Max. Resolution

3840 × 2160 (4K)

ROM / RAM

ROM: 4 GB

RAM: 2 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s to 1/100,000 s

Min. Illumination

Color: 0.0006 lux @ F1.2 (30 IRE)

B/W: 0.0003 lux @ F1.2 (30 IRE)

0 lux with illuminator on

S/N Ratio

>56 dB

Illumination Distance

IR: up to 60 m

Warm light: up to 50 m

Illuminator Control

Auto / Manual / Zoom priority

Illuminator Type

IR + Warm light (multi-core)

Angle Adjustment

Pan: 0°–355°

Tilt: 0°–80°

Rotation: 0°–355°

Lens

Lens Type

Motorized vari-focal

Focal Length

2.7 mm – 12 mm

Max. Aperture

F1.2

Field of View

H: 112°–48°

V: 58°–27°

D: 137°–55°

Close Focus Distance

0.16 m

Intelligence

IVS / Perimeter Protection

Intrusion, tripwire, fast moving detection

Loitering, people gathering, parking, stay detection

Face Detection

Face detection, snapshot, optimization, enhancement, attribute extraction

People Counting

Tripwire counting, area counting, queue management, report export

Heat Map

Yes

Video

Video Compression

H.265 / H.264 / H.264H / H.264B / MJPEG

Resolution Support

Up to 4K (3840 × 2160)

Multiple stream resolutions supported

WDR

130 dB

Image Enhancement

BLC, HLC, 3D DNR

EIS, defog, SSA

Privacy Masking

4–8 masks depending on channel

Audio

Audio Compression

G.711, G.726, AAC-LC, PCM

Built-in Audio

Dual MIC + Speaker

Network

Protocols

IPv4/IPv6, HTTP, HTTPS, RTSP, FTP, SMTP, NTP, SNMP, ONVIF

User Access

Up to 20–32 users depending on configuration

General

Power

12 VDC / PoE+

Power Consumption

Basic: ~5.3 W; Max: up to 24 W (with IR, heating, AI features)

Operating Temperature

–40 °C to +60 °C

Protection

IP67, IK10

Material

Metal (ADC12)

Weight

Approx. 1.4 kg

Dimensions

150 mm × Ø159 mm
