Key Specifications

Image Sensor

1/1.8" CMOS

Maximum Resolution

3840 × 2160 (8MP Ultra HD)

ROM / RAM

4 GB ROM / 2 GB RAM

Scanning System

Progressive Scan

Electronic Shutter Speed

1/3 s to 1/100,000 s

Minimum Illumination

0.0006 lux (Color), 0.0003 lux (B/W), 0 lux with Illuminator

S/N Ratio

Greater than 56 dB

Lens & Optics

Lens Type

Motorized Vari-Focal

Focal Length

2.7 mm – 12 mm

Maximum Aperture

F1.2

Lens Mount

φ14

Field of View

Horizontal: 114°–48°, Vertical: 59°–27°, Diagonal: 143°–56°

Iris Control

Auto P-Iris

Close Focus Distance

0.2 m (0.67 ft)

Illumination

IR Distance

Up to 60 m (196.85 ft)

Warm Light Distance

Up to 50 m (164.04 ft)

Illuminator Type

4 Multi-Core IR + Warm Lights

Light Control

Auto, Manual, Zoom Priority

Video

Video Compression

H.265, H.264, H.264H, H.264B, MJPEG

AI Coding

AI H.265, AI H.264, Smart H.265+, Smart H.264+

Maximum Frame Rate

3840 × 2160 @ 30 fps

Streaming Capability

4 Streams

Video Bit Rate

3 kbps – 16384 kbps

Bit Rate Control

CBR / VBR

Image Features

Wide Dynamic Range

130 dB WDR

Noise Reduction

3D Noise Reduction

Electronic Image Stabilization

Yes (EIS)

Defog

Yes

Smart Illumination

Yes

Smart Dual Light

Yes

Region of Interest

4 Areas

Privacy Masking

4 Mosaics or 8 Color Blocks

AI Analytics

Perimeter Protection

Intrusion, Tripwire, Fast Moving, Loitering, Parking, Stay Detection, People Gathering

Smart Motion Detection

SMD 4.0

AcuPick

AI-Powered Target Search and Matching

Face Detection

Face Detection, Attributes Extraction, Face Enhancement and Snapshot Optimization

People Counting

Tripwire, Area Counting, Queue Management with Reports

Heat Map

Supported

Video Metadata

Human, Face, Motor Vehicle and Non-Motor Vehicle Detection

Audio

Built-In Microphones

Dual Microphones

Built-In Speaker

Yes

Audio Compression

G.711a, G.711Mu, PCM, G.726, G.723

Network & Storage

Network Port

RJ-45 (10/100 Base-T)

Protocols

IPv4, IPv6, HTTP, HTTPS, RTSP, FTP, SFTP, SMTP, SNMP, ONVIF and more

ONVIF Support

Profile S, G, T and M

Maximum Users

20 Users

Storage Options

MicroSD up to 1 TB, FTP, SFTP, NAS

Alarm & Warning Features

Alarm Inputs / Outputs

1 Input / 1 Output

Light Warning

Warm Light Active Deterrence

Sound Warning

11 Built-In Alarm Sounds + 10 Custom Sounds

Interfaces

RS-485

1 Port

Audio Input

1 × RCA

Audio Output

1 × RCA

Power Output

12 VDC Output, Max. 165 mA

Power & Environmental

Power Supply

12 VDC, PoE+ (802.3at), ePoE

Dual Power Backup

Supported

Power Consumption

4.1 W Typical / 24.2 W Maximum

Operating Temperature

-40°C to +60°C (-40°F to +140°F)

Operating Humidity

≤95% RH

Protection Rating

IP67 Weatherproof, IK10 Vandal Resistant

Physical

Casing Material

Metal

Dimensions

127.6 mm × Φ122.0 mm (5.02" × Φ4.80")

Net Weight

0.92 kg (2.03 lb)

Gross Weight

1.15 kg (2.54 lb)
