Key Specifications

Camera Type

Network Bullet Camera

Image Sensor

1/1.8" CMOS

Maximum Resolution

2688 × 1520 (4MP)

Lens Type

Motorized Vari-Focal

Focal Length

8 mm – 32 mm

Maximum Aperture

F1.6

Field of View

Horizontal: 41°–16°, Vertical: 23°–9°, Diagonal: 48°–18°

Imaging & Illumination

Minimum Illumination

0.0005 lux (Color), 0.0003 lux (B/W), 0 lux with Illuminator

IR Distance

Up to 120 m (393.7 ft)

Warm Light Distance

Up to 80 m (262.5 ft)

Smart Illumination

Smart Dual Light with Auto, Manual, and Zoom Priority Modes

Wide Dynamic Range

140 dB WDR

Image Enhancement

3D NR, BLC, HLC, Defog, EIS, SSA, LDC

AI & Analytics

Perimeter Protection

Intrusion, Tripwire, Fast Moving, Loitering, People Gathering, Parking Detection, Stay Detection

AI Classification

Human, Vehicle, and Animal Detection

Face Detection

Face Capture, Enhancement, Attribute Extraction, Snapshot Optimization

People Counting

Tripwire Counting, Area Counting, Queue Management

Heat Map

Supported

AcuPick

AI Target Search for People, Animals, and Vehicles

Video & Compression

Video Compression

H.265, H.264, H.264H, H.264B, MJPEG

AI Coding

AI H.265, AI H.264, Smart H.265+, Smart H.264+

Streaming Capability

Up to 4 Streams

Frame Rate

4MP up to 30 fps

Video Bit Rate

3 kbps – 16384 kbps

Audio & Alarm

Built-In Microphone

Dual Microphones

Built-In Speaker

Yes

Audio Compression

G.711a, G.711Mu, PCM, G.726, G.723

Sound Warning

11 Built-In Alarms with Support for 10 Custom Sounds

Light Warning

Warm Light Active Deterrence

Storage & Network

Network Port

RJ-45 (10/100 Base-T)

Storage

MicroSD Card (Up to 1 TB), FTP, SFTP, NAS

Protocols

IPv4/IPv6, HTTP, HTTPS, RTSP, RTMP, FTP, SFTP, DHCP, DNS, SNMP, ONVIF, and More

Mobile Support

iOS and Android

Interfaces

Audio Input

1 × RCA

Audio Output

1 × RCA

Alarm Input

2 Channels

Alarm Output

2 Channels

RS-485

1 Port

Power & Protection

Power Supply

12 VDC ±30%, PoE+ (802.3at), ePoE

Maximum Power Consumption

24.2 W (PoE)

Protection Rating

IP67 Weatherproof, IK10 Vandal Resistant

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Physical Specifications

Housing Material

Metal

Dimensions

302.6 × 110.8 × 99.1 mm (11.91" × 4.36" × 3.90")

Net Weight

1.65 kg (3.64 lb)
