Key Specifications

Active or Passive

Active

System Type

Column

Configuration

2-way

System Continuous Power

1200 W

System Peak Power

2400 W

Max SPL @ 1m

129 dB

Freq Range (-10 dB)

35 Hz - 20 kHz

Freq Response (+/-3 dB)

40 Hz - 20 kHz

Bluetooth

Yes

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

12"

LF Voice Coil Size

2"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

300 W

HF Driver Type

Compression Driver

HF Diaphragm Material

PEI

HF Exit Size

1″

HF Power (RE:AES2-2012)

20 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

120° x 30°

Preset Library

No

Input Connector

2 x 1/4” Jack / XLR Combo, RCA

Waveguide Type

Mini EVO-Fold

Enclosure Material

Birch Plywood

Grille Material and Finish

Steel Black or White

Finish

Black or White Tough-Tone paint

Deployment

Ground

Pole Mount

None

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

n/a dB

System Rated Impedance

n/a

Recommended HPF = BW 18 dB/OCT.

35 Hz

Amplifier design

Class D

Input sensitivity

Switchable Balanced Mic / Line Level Input

Max input level

10 dBu

Line output

Socket XLR

Main Power

100-120 V~/200-240 V~,50/60 Hz

Power Supply

High Efficiency Switching Dual Mode Power Supply

Included Accessory

Quick Start Guide, AC cable

Unpacked - Height (mm)

Column: 1210 , Base Column: 590 , Subwoofer: 559

Unpacked - Width Front (mm)

Column: 126 , Base Column: 126 , Subwoofer: 454

Unpacked - Width Rear (mm)

Column: 126 , Base Column: 126 , Subwoofer: 454

Unpacked - Depth (mm)

Column: 145 , Base Column: 145 , Subwoofer: 576

Weight - Nett (kg)

Column: 10.5 , Base: 4.3 , Column + Base + speakON Cable: 15.3 , Subwoofer: 31

Weight - Gross (kg)

Column + Base + speakON Cable: 17.5 , Subwoofer: 34.3
