Key Specifications

Monitor Type & Configuration

Active 2-Way

Number of Included Monitors

Single Monitor

Enclosure

Bass-Reflex / Ported, Shielded

Total Power Output

245 W Peak

Drivers

Tweeter

1 × 1" (25.4 mm) Dome

Woofer

1 × 5.25" (13.33 cm) Composite Cone

Amplifiers

LF: 120 W / 145 W Peak
HF: 80 W / 100 W Peak

Performance

Frequency Range

41 Hz to 21.4 kHz (±6 dB)

Frequency Response

44 Hz to 21 kHz (±3 dB)

Maximum SPL

111 dB

Dynamic Range

121 dBA

Maximum Input Level

+24 dBu

Analog Input Sensitivity / Gain

0 dB to -15 dB

Protections & Limiting

Excursion Limiter, Peak Limiter, Soft Limiter, Thermal Limiting

Signal Processing

EQ

1 × HF Shelf
1 × Mid Notch / Peak
1 × LF Shelf

Crossover Frequency

1700 Hz, 48 dB/Octave Slope

App-Based Signal Processing

Yes

Maximum Sampling Rate

48 kHz / 24-Bit

Connectivity

Audio Input

1 × Combo XLR / 1/4" TRS Balanced Input

Digital Audio I/O

1 × RCA Coaxial S/PDIF Input
1 × RCA Coaxial S/PDIF Output

Network I/O

1 × RJ45 Ethernet

USB

No

Wireless

No

Mobile App Compatible

No

Power

AC Input Power

100 to 240 VAC, 50/60 Hz

Physical

Color

Anthracite Gray

Monitor Orientation

Vertical

Enclosure Material

MDF

Mounting Points

2 × M6 (Rear Panel)

Dimensions (W × H × D)

7.1 × 11.3 × 8.9" / 180.3 × 287 × 226.1 mm

Weight

11.9 lb / 5.4 kg
