Key Specifications

Wired/Wireless

Wired

Transducer Type

Condenser & Dynamic

Polar Pattern

Omnidirectional

Housing Material

Zinc Alloy

Connector Type

3-Pin Gold Plated XLR (Pin 2 Hot)

On/Off Switch

No

Performance Specifications

Maximum SPL

KM-3: >120 dB | KM-4: >135 dB | KM-5: >130 dB

Output Impedance

KM-3: <1000 Ω | KM-4: 250 Ω | KM-5: 250 Ω

Off Axis Rejection (at 180°)

KM-3: >18 dB | KM-4: >20 dB | KM-5: >22 dB

Sensitivity (0 dB=1 V/Pa)

KM-3: -46 dB | KM-4: -54 dB | KM-5: -54 dB

Physical Dimensions & Weight

Weight (kg)

KM-3: 0.12 | KM-4: 0.24 | KM-5: 0.17

Dimensions (H x W x D mm)

KM-3: 154 x 30 x 21
KM-4: 77.8 x 58.6 x 27
KM-5: 61.3 x 45.2 x 24
