Key Specifications

Product Model

Active KS12 CMA

System Type

2-Way Active Monitor Speaker with DSP

Power Rating

1600W (Program) / 3200W (Peak)

Max SPL

128dB Max.

Transducer & Audio Performance

LF Transducer

12" Woofer, 3" Voice Coil

HF Transducer

1" Compression Driver, 1.75" Voice Coil

Frequency Response

60Hz - 20KHz (-6dB)

Crossover Frequency

1.5K Hz (Linkwitz-Riley, 24dB slope)

DSP & Controls

DSP Presets

Flat / Loudness / User (Custom)

Inputs

Combo (Line/Mic) & Link-XLR

Protections

Thermal / Overload / Digital Limiter / Comp.

Physical & Mounting

Enclosure

Plywood, Black Paint, Metal Grille

Monitor Angle

Adjustable (20°, 25°, 30°, 35°, 40°)

Mounting

Pole-mount & 10x M10 Flying Points

Dimensions

291.9 x 470 x 570.3mm
