Key Specifications

Microphone Type

Large Diaphragm Condenser

Polar Pattern

Cardioid

Element Type

Permanently Biased Condenser

Frequency Response

20 Hz to 20 kHz

Maximum SPL

154 dB (2.5kΩ Load, with Pad)

Analog Output

1x XLR 3-Pin Male

Power Sources

Phantom Power

Microphone

Orientation

Side Address

Pad

-15 dB

Filter & EQ

80 Hz (18 dB/oct) / 115 Hz (6 dB/oct)

Circuitry

Solid-State (Class A Transformerless)

Performance

Sensitivity

-36 dBV/Pa (16 mV) at 1 kHz

Dynamic Range

126 dB (at 2.5kΩ Load)

Equivalent Noise Level

13 dB (A-Weighted)

Signal-to-Noise Ratio

81 dB

Power

Operating Voltage

11 to 52 VDC (Phantom Power)

Current Consumption

4.65 mA

Physical

Color

Silver (Charcoal Grey available in SL models)

Dimensions

ø: 2.2 x L: 7.37" / 56 x 187.2 mm

Weight

17.3 oz / 490.46 g

Packaging Info

Package Weight

4.945 lb

Box Dimensions (LxWxH)

14.55 x 10.4 x 6.5"
