Key Specifications

Frequency Response (-10 dB)

100 Hz - 20000 Hz

Max SPL @ 1m

126 dB

Coverage Angle (H x V)

150° x 30°

System Sensitivity

97 dB

Directivity Index (Q)

9

Power Section

Power Handling

200 W RMS / 800 W PEAK

Nominal Impedance

8 Ω

Constant Voltage Transformer

100 V

Power Selection (Taps)

60 W, 30 W, 15 W, 10 W

Crossover Frequency

2000 Hz

Protections

Dynamic active mosfet

Transducers

Dome Tweeter

4 x 1.0'', 1.0'' v.c.

Woofer

6 x 5.0'', 1.0'' v.c.

Standard Compliance

Safety Agency

CE compliant

Physical Specifications

Cabinet / Case Material

Baltic birch plywood

Hardware

4 x M5 inserts

Color Options

Black (RAL 9005), White (RAL 9003)

Dimensions (H x W x D)

826 x 135 x 140 mm / 32.52 x 5.31 x 5.51 inches

Weight

12.8 kg / 28.22 lbs

Shipping Information

Package Height

994 mm / 39.13 inches

Package Width

219 mm / 8.62 inches

Package Depth

219 mm / 8.62 inches

Package Weight

14.4 kg / 31.75 lbs
