Key Specifications

Product / Accessory Type

Portable Battery-Powered PA System

Enclosure Type & Design

Bass-Reflex Enclosure Design

Enclosure Material

MDF Construction

Mounting & Rigging Hardware

35.56 mm (1.40") Pole Socket

Environmental Resistance

None

Acoustic & Electrical Performance Specifications

Amplifier Output Power

100 W Peak Output / 25 W Continuous RMS

Amplifier Topology Class

Class-D Topology

High-Frequency Driver (HF)

1x 76.20 mm (3.00") HF Driver

Low-Frequency Driver (LF)

1x 254.00 mm (10.00") LF Driver with Ferrite Magnet

Frequency Response

65 Hz to 18 kHz

Maximum Sound Pressure Level (SPL)

117 dB Maximum SPL

Amplifier Protection Systems

Overcurrent Protection, Short Circuit Protection

Connectivity & Media Specifications

Audio Inputs

1x XLR / 1/4" TRS Combo Balanced/Unbalanced Mic Input,
1x 1/4" TS Mic / High-Impedance (Hi-Z) Instrument Input,
1x Stereo RCA Input (2RCA),
1x 3.5 mm (1/8") TRS Auxiliary Line Input

Media Playback & Storage

1x USB-A Port (Supports Up to 32 GB),
1x SD Card Slot (Supports Up to 32 GB)

Wireless Connectivity

Bluetooth Wireless Technology

Power & Battery Specifications

Battery Type & Capacity

Internal 12 V Rechargeable Battery, 5 Ah Capacity

AC Mains Input Voltage

100 to 120 VAC, 60 Hz / 220 to 240 VAC, 50 Hz

Power Consumption

50 W Maximum Power Consumption

Mains Connector

Standard IEC Inlet Terminal

Dimensions, Weight & Packaging Specifications

Product Dimensions (H×W×D)

525.80 mm x 414.00 mm x 327.70 mm (20.70" x 16.30" x 12.90")

Product Net Weight

16.19 kg (35.70 lbs)

Package Shipping Weight

19.57 kg (43.15 lbs)

Packaging Box Dimensions (L×W×H)

574.00 mm x 508.00 mm x 419.10 mm (22.60" x 20.00" x 16.50")
