Key Specifications

Aircraft

Takeoff Weight

Standard Takeoff Weight: Approx. 249 g
Max Takeoff Weight: Approx. 340 g

Dimensions

Folded (without propellers): 144×94×62 mm (L×W×H)
Unfolded (without propellers): 183×251×79 mm (L×W×H)

Max Ascent Speed

7 m/s (Sport mode)
5 m/s (Normal mode)
3 m/s (Cine mode)

Max Descent Speed

7 m/s (Sport mode)
5 m/s (Normal mode)
3 m/s (Cine mode)

Max Horizontal Speed

18 m/s (Sport mode)
12 m/s (Normal mode)
12 m/s (Tracking mode)

Max Takeoff Altitude

4500 m (Standard Battery)
3500 m (Battery Plus)

Max Flight Time

36 minutes (Standard Battery)
52 minutes (Battery Plus)

Typical Flight Time

23 minutes (Standard Battery)
37 minutes (Battery Plus)

Max Flight Distance

21 km (Standard Battery)
32 km (Battery Plus)

Max Wind Speed Resistance

10.7 m/s

Max Pitch Angle

35°

Operating Temperature

-10° to 40° C (14° to 104° F)

Global Navigation Satellite System

GPS + Galileo + BeiDou

Hovering Accuracy Range

Vertical:
±0.1 m (vision positioning)
±0.5 m (satellite positioning)

Horizontal:
±0.3 m (vision positioning)
±1.5 m (satellite positioning)

Internal Storage

42 GB

Class

C0/C1 (EU)

Camera

Image Sensor

1/1.3-inch CMOS, 48MP Effective Pixels

Lens

FOV: 82.1°
Format Equivalent: 24 mm
Aperture: f/1.7
Focus: 1 m to ∞

ISO Range

Video (Normal): 100-12800
Video (D-Log M): 100-3200
Slow Motion: 100-6400

Photo:
100-6400 (12 MP)
100-3200 (48 MP)

Shutter Speed

12MP Photo: 1/10000-2 s
48MP Photo: 1/16000-2 s

Max Image Size

8064×6048

Still Photography Modes

Single Shot: 12 MP / 48 MP
Burst Shooting: 3/5 frames
AEB: 3/5 frames at 2/3 EV step
Timed Shooting: 2/3/5/7/10/15/20/30/60 s

Photo Format

JPEG / DNG (RAW)

Video Resolution

H.265:
4K: 3840×2160@24/25/30/48/50/60/100fps
FHD: 1920×1080@24/25/30/48/50/60/100/200fps
2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps

H.264:
FHD: 1920×1080@24/25/30/48/50/60fps
2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps

Video Format

MP4 (H.264 / H.265)

Max Video Bitrate

130 Mbps

Color Mode and Sampling

Normal: 8-bit 4:2:0 (H.264), 10-bit 4:2:0 (H.265)
D-Log M: 10-bit 4:2:0 (H.265)

Digital Zoom

Video:
4K: 1-3x
FHD: 1-4x
2.7K Vertical Shooting: 1-3x

Photo:
12 MP: 1-3x
48 MP: 1-3x

Gimbal

Stabilization

3-axis mechanical gimbal (tilt, roll, pan)

Mechanical Range

Tilt: -126° to 67°
Roll: -49° to 49°
Pan: -30° to 30°

Controllable Range

Tilt: -90° to 40°

Max Control Speed

100°/s

Angular Vibration Range

±0.01°

Video Transmission

Transmission System

O4

Live View Quality

Up to 1080p/60fps

Max Transmission Distance

IC: 15 km
CE/SRRC/MIC: 8 km

Max Download Speed

O4: 10 MB/s
Wi-Fi 6: Up to 50 MB/s

Lowest Latency

Approx. 120 ms

Battery

Capacity

Standard Battery: 2788 mAh
Battery Plus: 4680 mAh

Weight

Standard Battery: Approx. 74 g
Battery Plus: Approx. 118 g

Nominal Voltage

7 V (Standard Battery)
7.16 V (Battery Plus)

Battery Type

Li-ion

Energy

19.52 Wh (Standard Battery)
33.51 Wh (Battery Plus)

Charging Temperature

5° to 40° C (41° to 104° F)

Charging Time

Standard Battery:
45 mins (Charging Hub)
73 mins (via drone)

Battery Plus:
56 mins (Charging Hub)
102 mins (via drone)

Battery Charging Hub

Input

5 V / 9 V / 12 V / 15 V / 20 V, up to 3.25 A

Output

5 V / 9 V / 12 V / 15 V / 20 V, up to 3 A

Charging Type

Three batteries charged in parallel

Compatibility

DJI Lito X1 Intelligent Flight Battery
DJI Lito Series Intelligent Flight Battery Plus

Bluetooth

Protocol

Bluetooth 5.4

Operating Frequency

2.4000-2.4835 GHz

Transmitter Power (EIRP)

< 10 dBm
