Key Specifications

Product Type

Compact Analog Audio Mixer with Digital Effects

DSP Engine / Effects

10 DSP Effect Families with 10 Variations Each (100 Total Presets)

A/D & D/A Conversion Resolution

24-bit

DSP Controls & Indicators

Rotary Preset Encoder, DSP Mute Switch, Peak LED Indicator

Phantom Power

47V DC ±2V (Pins 2/3 and Pin 1)

Microphone & Line Inputs

Microphone Inputs

7x 3-Pin XLR (Balanced) with DNA Preamps

Mic Frequency Response & Gain

20 Hz to 20 kHz (+0.5 dB) | Gain Range: 0 to 45 dB

Mic THD+N & SNR

<0.02% (@ 0 dBu, 1 kHz) | SNR: 90 dB

Line Inputs

12x 1/4" TRS Jack (Balanced)

Line Frequency Response & Sensitivity

20 Hz to 20 kHz (+0.5 dB) | Sensitivity: -15 to 30 dBu

Line THD+N

<0.03% (@ 0 dBu, 1 kHz)

Impedance & System Performance

Input Impedances

Mic Inputs: 51.1 kΩ | Insert Return: 200 kΩ | All Other Inputs: >100 kΩ

Output Impedances

2-Track Outputs: 10 kΩ | All Other Outputs: 20 kΩ

Main Mix Bus Noise

-64 dBr (Ref: +4 dBu, Fader @ 0 dB, Channels Muted / Unity Gain)

Equalization & Processing

Channel EQ

High Shelving: ±15 dB @ 12 kHz
Mid-Bell (Mono): ±15 dB @ 2.5 kHz
Low Shelving: ±15 dB @ 80 Hz

Graphic Master EQ

9-Band Graphic EQ (63, 125, 250, 500 Hz; 1, 2, 4, 8, 16 kHz), ±15 dB

Power, Dimensions & Packaging

Power Supply Input

100-120 VAC, 60 Hz (Standard IEC Receptacle)

Power Consumption & Fuse

Consumption: 50 W | Fuse: 1.25 A

Unit Dimensions & Weight

358mm x 346mm x 80mm (14.1" x 13.6" x 3.1") | Net Weight: 4.1 kg (9.0 lbs)

Packaging Info

Box: 457mm x 432mm x 157mm (18.0" x 17.0" x 6.2") | Gross Weight: 5.67 kg (12.5 lbs)
