Key Specifications

Part Number

939-002180

Product Type

Managed Docking Station

Display Size

8" (203.2 mm Diagonal)

Display Type

IPS LCD with LED Backlighting

Resolution

1280 x 800

Touchscreen

Capacitive, 5-Point Multi-Touch

Brightness

300 nits

Contrast Ratio

800:1

Viewing Angle

85° (Up/Down/Left/Right)

Position Angle

60°

Connectivity

Front USB-C Ports

2 x USB-C (7.5W Each)

Front USB-A Ports

1 x USB-A (7.5W)

Rear USB-C Ports

1 x USB-C (7.5W)

Rear USB-A Ports

2 x USB-A (7.5W Each)

Laptop Connection

1 x USB-C (Up to 100W Charging)

HDMI

1 x HDMI 2.0 (Up to 4K 3840 x 2160 @ 60Hz HDR)

DisplayPort

1 x DisplayPort 1.4 (Up to 4K 3840 x 2160 @ 60Hz HDR)

Ethernet

1 x RJ45 Gigabit Ethernet (10/100/1000 Mbps)

DC Power Input

1 x DC Power Connection

Wireless Connectivity

Wi-Fi

802.11a/b/g/n/ac

Bluetooth

Bluetooth 5.0 (Reserved for Future Use)

Ambient Light Sensor

Yes

Compatibility & Management

Management Platform

Logitech Sync

Operating Platform

Logitech CollabOS

Security

Full Disk Encryption

AES-128

Data Encryption

Symmetric Keys, PKI

Device Identity

Protected by Device Attestation

Key Protection

Arm TrustZone, RPMP

Kensington Lock Slot

Yes

Cable Security

Advanced Cable Retention and Security

Environmental

Operating Temperature

0°C to 40°C

Operating Humidity

10% to 90%

Storage Temperature

-40°C to 70°C

Storage Humidity

0% to 95%

Dimensions & Weight

Dimensions (H x W x D)

141.2 x 201 x 176.9 mm

Weight

1.0 kg

Sustainability

Recycled Plastic

36% Certified Post-Consumer Recycled Plastic

Aluminum

Low Carbon Aluminum

Packaging

FSC™-Certified Paper Packaging

Carbon Neutral

Yes
