Key Specifications

Frequency Range/Response

35 Hz to 111 Hz (-10 dB)
41 Hz to 98 Hz (-6 dB)

Speaker Type

Active Line Array Subwoofer

Enclosure Type

Bass-Reflex

Total Output Power

4000 W

Amplifier Class

Class-D

Drivers

LF Driver

1x 18" / 45.7 cm Woofer

Performance

Frequency Range/Response

35 Hz to 111 Hz (-10 dB)
41 Hz to 98 Hz (-6 dB)

Maximum SPL

138 dB (Peak)

Signal Processing

EQ & Filters

No

Dynamic Processing

Limiter

Alignment Delay

No

Connectivity

Audio I/O

1x XLR 3-Pin Line Input
1x XLR 3-Pin Line Thru

Network I/O

2x RJ45 (Dante)

USB I/O

No

Wireless

No

Mobile App Compatible

Yes: iPadOS Only
App Name: QSC SysNav

Power

AC Input Power

100 to 240 VAC, 50 / 60 Hz

AC Power I/O

1x powerCON Input
1x powerCON Output

Current Consumption

100 VAC: 3.6 A (1/8 Power)
120 VAC: 3 A (1/8 Power)
230 VAC: 1.7 A (1/8 Power)

Physical

Color

Black

Mounting

Stand Mount
2 x M20-Threaded Pole Socket (Side, Top)
Suspension Points
8 x M10 Fly Point (Side, Top)

Construction Material

Metal Grille, Plywood

Environmental Resistance

No

Dimensions

31.1 x 25.2 x 20.5" / 79 x 64 x 52.1 cm

Weight

110 lb / 49.9 kg

Packaging Info

Package Weight

134 lb

Box Dimensions (L × W × H)

35 x 29.5 x 22.5"
