Key Specifications

Product Model

LVA16.150

Amplifier Topology

Switching Power Class-D

Power Output (4Ω)

130W x 8 Channels

Power Output (8Ω)

70W x 8 Channels

Frequency Response

100 Hz to 15 kHz (+0/-1dB)

Technical Performance

S/N Ratio / THD+N

> 95 dB / < 0.1%

Input Impedance

20kΩ Balanced / 10kΩ Unbalanced

Damping Factor

> 200 (1 kHz, 8Ω)

Crosstalk

> 70 dB

Connectivity & Protection

Connectors

Euro Block (Inputs and Outputs)

Protections

Short circuit, thermal, ultrasonic, RF, muting

Indicators

Signal, Clip, Power, Protection (LED)

Physical & Power

Dimensions (HxWxD)

44 x 483 x 360 mm (1U Rack)

Weight

6.8 kg (14.99 lbs)

Power Supply

110-120V / 220-240V AC 50/60Hz
