Key Specifications

Audio Inputs

Mono Input Channels

6 Channels (Switchable LINE, MIC, or Phantom)

LINE Input Specs

-10 dB, 2.4 k ohms

MIC / Phantom Specs

-46 dB, 2.4 k ohms (+24V DC Phantom)

Stereo Inputs (L, R)

3 Channels (-10 dB / 10 kOhms)

Stereo Connectors

RCA jack, Stereo mini jack

Audio Outputs

Mono Outputs

2 Channels (0 dB, Removable Terminal Block 3-pin)

Stereo Output (L, R)

1 Channel

Recording Output (L, R)

1 Channel (-10 dB, RCA jack)

System Performance

Frequency Response

20 Hz to 20 kHz

Digital Sampling

48 kHz / 24 bits

Dynamic Range

90 dB or more (IHF-A weighted)

Bus Line Configuration

Monaural Channel x 2, Stereo Channel x 1

Signal Processing

Core Functions

ARC (Automatic Resonance Control)

Feedback Control

FBS (Feedback Suppressor)

Gain & Muting

ACG (Automatic Clipguard), Automatic Mute

Physical Characteristics

Dimensions (W x H x D)

16.5 x 1.7 x 13.4" (420.0 x 44.0 x 341.3 mm)

Weight

8.8 lb (4.0 kg)

Construction

Steel Cabinet, Black Finish

Package Weight

12.6 lb

Box Dimensions

22.835 x 20.472 x 3.937"
