Key Specifications

Power Source

100 – 120 VAC, 60 Hz

Power Consumption

30 W

Frequency Response

20 Hz - 20 kHz, ±1 dB

Sampling / Conversion

48 kHz / 24-bit A/D & D/A

Dynamic Range

100 dB or more (IHF-A weighted)

Distortion / Crosstalk

≤0.03% (1 kHz) / ≤−80 dB

Audio Inputs

Monaural Inputs (x8)

Removable Terminal Block (3P); Phantom Power (+24V DC)

Mono Gain (PAD ON)

Min: +4 dB (Max +24 dB) | Max: −14 dB (Max +6 dB)

Mono Gain (PAD OFF)

Min: −10 dB (Max +10 dB) | Max: −56 dB (Max −36 dB)

Stereo Inputs (7 Channels)

RCA Jack (Groups 1-A/B/C, 2-A/B/C) + Front Mini Jack

Stereo Trim / Gain

−10 dB (Max +10 dB); Trim −∞ to 0 dB

Audio Outputs

Main Outputs (x4)

+4 dB (Max +24 dB); Terminal Block (3P); ≥600Ω load

REC OUT (L, R)

–10 dB (Max +10 dB); RCA Jack; ≥1 kΩ load

Signal Processing

ARC (Auto Resonance Control)

Automatic EQ curve creation (4 output channels)

FBS (Feedback Suppressor)

8 channels (each monaural input)

Tone Controllers

Bass, Mid (Parametric), Treble per input channel

Control & Connectivity

Contact I/O

8 Input / 8 Output Channels (Terminal Block 10P)

Network

10BASE-T/100BASE-TX; TCP/IP; RJ45

Remote Control Panels

2 channels; Max 8 units/channel; 800m total cabling

Physical Specifications

Dimensions (W x H x D)

19 x 6.97 x 6.19" (482.6 x 177.1 x 157.2 mm)

Weight

11.24 lb (5.1 kg)

Operating Conditions

0 to 40 ºC; 90 %RH (no condensation)

Package Info

14.85 lb | 22.8 x 10.6 x 10.0"
