Key Specifications

System Architecture & Power

Power Source

220 - 240 V AC, 50/60 Hz

Power Consumption

40 W

Module Slots

8 Slots (Modular Construction)

Audio Inputs

Max. 8 channels (via optional modules)

Audio Outputs

2x Preamplifier Outputs (0 dB, 600 Ω, Balanced)

Digital Processing

24-bit / 48 kHz Sampling Rate

Audio Performance

Frequency Response

20 Hz - 20 kHz, +1, -3 dB

Total Harmonic Distortion

0.01 % (at A-weighted, 1 kHz)

S/N Ratio

90 dB (Output volume min.) | 61 dB (Max volume)

Crosstalk

-64 dB or less (at 20 kHz)

DSP & Signal Processing

Parametric EQ

10 bands per channel (±12 dB, Q: 0.3 - 5)

Speaker EQ / Filters

30 TOA Presets; High-pass / Low-pass (-12 dB/oct)

Dynamics / Delay

Compressor (Depth 1-5); Delay (0-40 ms)

Memory / Scenes

32 Scene/Event Memory Slots

Control & Connectivity

Serial Control

RS-232C (D-sub 9-pin female)

Control I/O

4 Inputs / 4 Outputs (Removable terminal block)

Remote Volume

2 channels (10 kΩ linear or 0 to +10 V DC)

Physical Specifications

Dimensions (W x H x D)

420 × 107.6 × 353 mm (16.54 × 4.24 × 13.9")

Weight

6 kg (13.23 lb)

Operating Temperature

-10 ºC to +40 ºC (14 ºF to 104 ºF)
