YAMAHA MA2120
YAMAHA MA2120
|
Key Specifications |
|
|
Form Factor / Type |
Tabletop (Rack-Mountable with Included Hardware) |
|
Number of Amplifier Channels |
2 |
|
Load Impedance / Voltage Support |
4 / 8 Ohms, 70 / 100 V |
|
Power Rating per Channel |
2×120 W at 4Ω | 2×100 W at 8Ω | 2×120 W at 70/100V |
|
Amplifier Class |
Class D |
|
Frequency Response |
20 Hz – 20 kHz (4/8Ω) | 50 Hz – 20 kHz (70/100V) |
|
Total Harmonic Distortion (THD) |
≤ 0.2% |
|
Crosstalk |
< -70 dB |
|
Signal Processing |
DSP: Yes | Audio Delay: No | EQ & Filters: High-Pass Filter | Dynamics: Limiter |
|
Analog Audio I/O |
3× 6-Pin Balanced Line Input |
|
Digital / Network I/O |
No |
|
Other I/O |
1× RJ45 Control |
|
USB / Phantom / Wireless |
No |
|
Power Requirements |
100–240 VAC, 50/60 Hz | AC Connector: IEC | Power Consumption: 60 W (1/8 power) |
|
Display |
Single-LED Indicators Only |
|
Rackmount Size |
1 U (with Included Hardware) |
|
Cooling |
Convection |
|
Certifications |
CE |
|
Operating Conditions |
0–40°C / 32–104°F |
|
Dimensions (W×H×D) |
480 × 45 × 379 mm / 18.9 × 1.8 × 14.9" |
|
Weight |
4.9 kg / 10.8 lb |
