Key Specifications

Channels of I/O

2 Inputs / 2 Outputs

Maximum Sampling Rate

48 kHz / 24-Bit

Number of Microphone Inputs

1

Analog Audio I/O

1x Combo XLR-1/4" TRS Mic/Line Input
1x 1/8" / 3.5 mm TRS Line/Aux Input
2x 1/4" TRS Line Output
1x 1/8" / 3.5 mm TRS Headphone Output
1x 1/8" / 3.5 mm TRRS Headset In/Out

Digital Audio I/O

No

Host Connection

2x USB-C

Power Requirements

USB Bus Power

General

Display

No

Channels of I/O

2 Inputs / 2 Outputs

Built-In DSP

No

Maximum Sampling Rate

48 kHz / 24-Bit

Number of Microphone Inputs

1

Built-In Microphone

No

Signal Processing

Pad

No

High-Pass Filter

No

Solo/Mute

Mute per Input Channel

Connectivity

Analog Audio I/O

1x Combo XLR-1/4" TRS Mic/Line Input
1x 1/8" / 3.5 mm TRS Unbalanced Line/Aux Input
2x 1/4" TRS Line Output
1x 1/8" / 3.5 mm TRS Headphone Output
1x 1/8" / 3.5 mm TRRS Headset In/Out

Phantom Power

No

Digital Audio I/O

No

Host Connection / USB

2x USB-C

Host Connection Protocol

USB 2.0, USB 3.1/3.2 Gen 2

USB (Non-Host)

1x USB-C (USB 3.1 Gen 2, Power Input)

Sync I/O

No

Network I/O

No

MIDI I/O

No

Expansion Slots

No

Other I/O

1x HDMI Expansion Input
1x HDMI Expansion Thru

Wireless

No

Digital Audio

Sample Rates

48 kHz

Sample Rate Conversion

No

Bit Depths

24-Bit

Sync Sources

No

Audio Storage & Playback

Media/Memory Card Slot

No

Compatibility

OS Compatibility

macOS / Windows

Mobile Device Compatibility

No

Required Hardware

USB-C Port

Power

Power Requirements

USB Bus Power

Physical

Dimensions

8.4 x 3.7 x 2.4" / 21.3 x 9.4 x 6.1 cm

Weight

1.3 lb / 0.6 kg

Packaging Info

Package Weight

2.12 lb

Box Dimensions (L × W × H)

9.8 x 4.9 x 4.6"
