Key Specifications

Jacket Diameter

PVC 3.7 mm

AWG

24

No. of Inner Conductors

2 x 0.22 mm²

Copper Strand per Conductor

20 x 0.12 mm

Conductor Insulation

LLDPE 1.40 mm

Drain Wire

25 x 0.12 mm Tin copper

Shielding

AL fleece

Shielding Factor

100%

Temperature Range

Min. -20°C / Max. +70°C

Packaging

100/300 m roll

Electrical Data

Capac. Cond./Cond. (per 1 m)

52 pF

Capac. Cond./Shield. (per 1 m)

108 pF

Cond. Resistance (per 1 m)

80 mΩ

Shield. Resistance (per 1 m)

52 mΩ
