BELDEN MELINE S12
BELDEN MELINE S12
|
Key Specifications |
|
|
Acoustical Specifications |
|
|
Frequency Response (-3 dB) |
45 Hz–18 kHz |
|
Max SPL @ 1 m |
118 dB / 124 dB (Peak) |
|
Dispersion (H × V) |
90° × 40° |
|
Transducers |
|
|
Compression Driver |
6 × 2" Full-frequency unit |
|
Woofer |
1 × 12" Woofer |
|
Input / Output Section |
|
|
Input Connectors |
Three channel balanced input XLR / 6.35 / TRS / RCA |
|
Power Section |
|
|
Total Power |
400 W (RMS); 800 W (MUSIC); 1600 W (PEAK) |
|
High Frequencies |
150 W |
|
Low Frequencies |
250 W |
|
Nominal Impedance |
4 Ω |
|
Cooling |
Forced air-cooled drives |
|
Power Consumption (Static) |
28 W |
|
Power Consumption (Rated) |
400 W |
|
Voltage Range |
AC 220V–230V~, 50Hz/60Hz |
|
Physical Specifications |
|
|
Cabinet / Case Material |
Plywood column loudspeaker |
|
Handles |
1 × Aluminum handle |
|
Grille |
Cabinet coated by Polyurethane paint; grille is powder coated, inside is black cotton |
|
Color |
Black |
|
Size |
|
|
Dimensions (W × D × H) |
350 × 420 × 1876 mm (13.8 × 16.5 × 73.9 in) |
|
Package Dimensions (W × D × H) |
650 × 445 × 630 mm (25.6 × 17.5 × 24.8 in) |
|
Weight |
|
|
Net Weight |
20.8 kg (45.9 lb) |
|
Gross Weight |
22.2 kg (48.9 lb) |
