Key Specifications

Acoustical Specifications

Frequency Response (-3 dB)

45 Hz–18 kHz

Max SPL @ 1 m

119 dB / 125 dB (Peak)

Dispersion (H × V)

90° × 40°

Transducers

Compression Driver

8 × 2" Full-frequency unit

Woofer

1 × 15" Woofer

Input / Output Section

Input Connectors

Three channel balanced input XLR / 6.35 / TRS / RCA

Power Section

Total Power

550 W (RMS); 1100 W (MUSIC); 2200 W (PEAK)

Mid Frequencies

200 W

Low Frequencies

350 W

Nominal Impedance

4 Ω

Cooling

Forced air-cooled drives

Power Consumption (Static)

28 W

Power Consumption (Rated)

400 W

Voltage Range

AC 110V/230V, 50Hz/60Hz

Physical Specifications

Cabinet / Case Material

Plywood column loudspeaker

Handles

2 × Wooden handles + 1 × Aluminum handle

Grille

Cabinet coated by Polyurethane paint; grille is powder coated, inside is black cotton

Color

Black

Size

Dimensions (W × D × H)

420 × 490 × 2021 mm (16.5 × 19.3 × 79.6 in)

Package Dimensions (W × D × H)

720 × 515 × 655 mm (28.3 × 20.3 × 25.8 in)

Weight

Net Weight

27.3 kg (60.2 lb)

Gross Weight

32.55 kg (71.8 lb)
