Key Specifications

Input Channels

2 x XLR-1/4" Combo (Mic/Line)
2 x 1/4" / 6.3 mm Stereo (Line)

Phantom Power

+48 V Switchable, Channels 1, 2

Output Channels

2 x XLR Stereo
2 x 1/4" / 6.3 mm Stereo
1 x 1/4" / 6.3 mm Headphone

Bus

1 x 1/4" / 6.3 mm Stereo

Pad

26 dB (Mono Channels)

High-Pass Filter (HPF)

80 Hz, 12 dB/Oct (Mono Channels)

Equalization

EQ High (Mono Channels)

Gain: ±15 dB, Frequency: 10 kHz Shelving

EQ Low (Mono Channels)

Gain: ±15 dB, Frequency: 100 Hz Shelving

Performance

Total Harmonic Distortion

0.01% @ +8 dBu (20 Hz – 20 kHz), Gain Knob: Min
0.003% @ +18 dBu (1 kHz), Gain Knob: Min

Frequency Response

20 Hz – 20 kHz ±0.5 dB, Refer to Nominal Output Level @ 1 kHz, Gain Knob: Min

Equivalent Input Noise

-128 dBu (Mono Input Channel, Rs: 150 Ohms, Gain Knob: Max)

Residual Output Noise

-102 dBu (Stereo Out, Stereo Level Knob: Min)

Crosstalk

-88 dB

Indicators / Metering

LED Indicator

Turns on when post EQ signal reaches 3 dB below clipping

Level Metering

2 x 7-Segment LED Meter (Peak, +6, +3, 0, -3, -10, -20 dB)

Power

Power Requirements

PA-130 (12 VDC / 1 A), 120 VAC, 60 Hz
MU18 (12 VDC / 1.5 A), 100–240 VAC, 50/60 Hz
Or Equivalent Recommended by Yamaha

Power Consumption

12 W

Physical

Dimensions (H × W × D)

5.9 × 2.4 × 7.9 in / 149 × 62 × 202 mm

Net Weight

1.98 lb / 0.9 kg

Package Weight

3.27 lb

Box Dimensions (L × W × H)

10.65 × 9.65 × 4.8 in
