Key Specifications

Effects Engine

SPX Algorithm: 6 Programs (3 Reverb, 3 Delay)

Input Channels

2× XLR-1/4" Combo (Mic/Line)
2× 1/4" / 6.3 mm Stereo (Line)

Phantom Power

+48 V Switchable, Channels 1 and 2

Output Channels

2× XLR Stereo
2× 1/4" / 6.3 mm Stereo
1× 1/4" / 6.3 mm Headphone

Bus

1× Stereo

Pad

26 dB (Mono Channels)

High-Pass Filter (HPF)

80 Hz, 12 dB/Oct (Mono Channels)

Equalizer

High: ±15 dB @ 10 kHz (Shelving)
Low: ±15 dB @ 100 Hz (Shelving)

LED

LED turns on when post-EQ signal reaches 3 dB below clipping

Level Metering

2× 7-Segment LED Meter (Peak, +6, +3, 0, -3, -10, -20 dB)

Performance

Total Harmonic Distortion (THD)

0.01% @ +8 dBu (20 Hz–20 kHz), Gain Knob: Min
0.003% @ +18 dBu (1 kHz), Gain Knob: Min

Frequency Response

20 Hz–20 kHz ±0.5 dB (Nominal Output @ 1 kHz, Gain Knob: Min)

Equivalent Input Noise

-128 dBu (Mono Input Channel, Rs: 150 Ohms, Gain Knob: Max)

Residual Output Noise

-102 dBu (Stereo Out, Level Knob: Min)

Crosstalk

-88 dB

Power

Power Requirement

PA-130 (12 VDC / 1 A), 120 VAC, 60 Hz
MU18 (12 VDC / 1.5 A), 100–240 VAC, 50/60 Hz
or equivalent recommended by Yamaha

Power Consumption

12 W

Physical

Dimensions (W × H × D)

5.9 × 2.4 × 7.9" / 149 × 62 × 202 mm

Net Weight

1.98 lb / 0.9 kg

Packaging Info

Package Weight

3.27 lb

Box Dimensions (L×W×H)

10.7 × 9.75 × 4.75"
