Key Specifications

Number of Analog Input Channels

10 (4 Mono / 3 Stereo)

Number of Mic Preamps

4

Analog Output Channels

2× Stereo Master Output
1× Stereo Control Room/Monitor Output
1× Mono Aux Send Output
1× Stereo Headphone Output

Mix Routing

1× Stereo Bus/Subgroup
1× Aux Bus/Subgroup

EQ

3-Band EQ (Mono Channels)
2-Band EQ (Stereo Channels)

Built-In Effects

No

Wireless

No

Rack Mountable

No

Mixer

Faders & Level Adjustment

7× Channel Knob

Meters

2× 7-Segment LED

Signal Processing

Input Pad

-26 dB (Mono Channels)

Dynamic Processing

No

EQ Parameters

High: ±15 dB @ 10 kHz (Shelving)
Mid: ±15 dB @ 2.5 kHz (Notch/Peak)
Low: ±15 dB @ 100 Hz (Shelving)

Filters

High-Pass: 80 Hz, 12 dB/Octave

Solo/Mute

No

Graphic EQ

No

Built-In Effects

No

Performance

Frequency Response

20 Hz to 48 kHz +0.5/-1 dB (Min Gain)

Noise Floor

Main Output: -102 dBu (Master Level at -∞)

THD

0.02% @ Min Gain (+14 dBu, Full Range)
0.003% @ Min Gain (+24 dBu, 1 kHz)

Connectivity

Analog Inputs

4× Combo XLR-1/4" Balanced Input
6× 1/4" Unbalanced Stereo Input (3 Stereo Pairs)

Analog Outputs

2× XLR 3-Pin Balanced Stereo Main Output
2× 1/4" Unbalanced Stereo Monitor Output
1× 1/4" TRS Stereo Headphone Output
1× 1/4" Aux Send

Phantom Power

+48 V, Selectable On/Off (on 4 Channels)

Digital I/O

No

Wireless

No

Power

AC Input Power

38 VAC, 50 / 60 Hz

Power Supply Output

38 VAC @ 0.62 A

Physical

Rack Mountable

No

Dimensions (W × H × D)

9.6 × 2.8 × 11.6" / 244 × 71 × 294 mm

Weight

4.2 lb / 1.9 kg
