Key Specifications

Max I/O Capacity

10× Input / 2× Output

Number of Analog Input Channels

10 (4 Mono / 3 Stereo)

Number of Mic Preamps

4

Analog Output Channels

1× Stereo Master Output

Mix Routing

Stereo Main Mix

Built-In Effects

24× Stereo Effects

Rack Mountable

No

Mixer

Faders & Level Adjustment

No Faders

Meters

2× 7-Segment LED (Main Meter)

Meter Range

-20 dB to +17 dB Peak/Clip

Signal Processing

Gain/Trim Range

-6 dB to +38 dB

Input Pad

-26 dB (Mono Channels)

Dynamic Processing

Compressor

EQ

3-Band EQ (Mono Channels)
2-Band EQ (Stereo Channels)

EQ Parameters

Mono: High ±15 dB @ 10 kHz, Mid ±15 dB @ 2.5 kHz, Low ±15 dB @ 100 Hz
Stereo: High ±15 dB @ 10 kHz, Low ±15 dB @ 100 Hz

Filters

High-Pass: 80 Hz

Solo/Mute

No

Graphic EQ

No

Performance

Frequency Response

20 Hz to 48 kHz +0.5 / -1 dB (1 kHz)

Max Input Level

+30 dB @ Max Gain

Output Level

+24 dB @ Max Gain

Crosstalk

-83 dB

EIN

-128 dBu @ Max Gain

Noise Floor

-102 dB (Residual Output Noise)

THD+N

0.02% @ Min Gain (+14 dBu, 20 Hz–20 kHz)
0.003% @ Min Gain (+24 dBu, 1 kHz)

Connectivity

Analog Inputs

4× Combo XLR-1/4" Mic/Line Input
6× 1/4" TRS Stereo Line Input (3 Stereo Pairs)
2× RCA TS Stereo Line Input
1× 1/4" TRS Footswitch Input

Analog Outputs

2× XLR 3-Pin Balanced Stereo Main Output
2× 1/4" TRS Balanced Stereo Main Output
2× 1/4" TRS Monitor Output
1× 1/4" TRS FX Send
1× 1/4" TRS Stereo Headphone Output

Phantom Power

+48 V, Selectable On/Off (4 Channels)

Digital / MIDI / USB I/O

No

Power

AC Input Power

120 VAC, 60 Hz

Power Supply Output

38 VAC

Power Consumption

22.9 W
