Key Specifications

Built-In Effects

SPX Algorithm: 24 Programs, Parameter Control: 1, Foot SW: 1 (FX RTN CH on/off)

Phantom Power

+48 V switchable, channels 1 - 4

Digital I/O

USB: USB Audio Class 2.0 compliant
Sampling Frequency: max 192 kHz
Bit Depth: 24-bit

Input Channels

4× Mono [Mic/Line]
2× Mono/Stereo [Mic/Line]
2× Stereo [Line]

Output Channels

2× Stereo Out
1× Monitor Out
1× Headphone Out
2× Aux Out
2× Group Out

Bus

Stereo: 1
AUX: 2
GROUP: 2

Pad

26 dB (Mono)

High-Pass Filter (HPF)

80 Hz, 12 dB/Oct (Mono/Stereo: MIC only)

Compressor

Threshold: +22 dBu to -8 dBu
Ratio: 1:1 to 4:1
Output Level: 0 dB to 7 dB
Attack Time: approx. 25 msec
Release Time: approx. 300 msec

Equalizer

High Gain: +15/-15 dB, 10 kHz Shelving
Mid Gain: +15/-15 dB, 2.5 kHz Peaking
Low Gain: +15/-15 dB, 100 Hz Shelving

LED

Peak LED turns on when post EQ signal reaches 3 dB below clipping

Level Metering

2× 12-Segment LED Meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB]

Total Harmonic Distortion (THD)

0.03% @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min
0.005% @ +24 dBu (1 kHz), GAIN knob: Min

Frequency Response

+0.5 / -1.5 dB (20 Hz to 48 kHz), refer to nominal output level @ 1 kHz, GAIN knob: Min

Equivalent Input Noise

-128 dBu (Mono input channel, Rs: 150 Ω, GAIN knob: Max)

Residual Output Noise

-102 dBu (Stereo Out, Stereo Master Fader: Min)

Crosstalk

-78 dB

Power Requirement

AC 100–240 V, 50 / 60 Hz

Power Consumption

22 W

Dimensions (W × H × D)

12.1 × 4.6 × 16.6" / 308 × 118 × 422 mm

Net Weight

9.3 lb / 4.2 kg
