Key Specifications

Phantom Power

+48 V switchable, channels 1 - 12

Input Channels

8× Mono [Mic/Line]
2× Mono/Stereo [Mic/Line]
2× Stereo [Line]

Output Channels

2× Stereo Out
1× Monitor Out
1× Headphone Out
4× Aux Out
4× Group Out

Busses / Aux

Stereo: 1
AUX: 4
GROUP: 4

Pad

26 dB (Mono)

High-Pass Filter (HPF)

80 Hz, 12 dB/oct (Mono/Stereo MIC only)

Compressor

Threshold: +22 dBu to -8 dBu
Ratio: 1:1 to 4:1
Output Level: 0 dB to 7 dB
Attack Time: Approx. 25 msec
Release Time: Approx. 300 msec

Equalizer

High: ±15 dB @ 10 kHz (Shelving)
Mid: ±15 dB @ 250 Hz - 5 kHz (Peaking, Mono Channels)
Low: ±15 dB @ 100 Hz (Shelving)

LED

Peak LED turns on when post EQ signal reaches 3 dB below clipping

Total Harmonic Distortion (THD)

0.03% @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min
0.005% @ +24 dBu (1 kHz), GAIN knob: Min

Frequency Response

+0.5 dB / -1.5 dB (20 Hz to 48 kHz), Refer to nominal output level @ 1 kHz, GAIN knob: Min

Equivalent Input Noise (EIN)

-128 dBu (Mono Input Channel, Rs: 150 Ω, GAIN knob: Max)

Residual Output Noise

-102 dBu (Stereo Out, Stereo Master Fader: Min)

Crosstalk

-78 dB

Power Requirement

AC 100 - 240 V, 50 / 60 Hz

Power Consumption

30 W

Dimensions (W × H × D)

17.5 × 5.1 × 19.7" / 444 × 130 × 500 mm

Net Weight

14.6 lb / 6.6 kg

Packaging Info

Package Weight: 19.9 lb
Box Dimensions (L×W×H): 21.9 × 20.4 × 8.4"
