Key Specifications

Number of Analog Input Channels

12 (8 Mono / 2 Mono/Stereo / 2 Stereo)

Number of Mic Preamps

12

Analog Output Channels

2× Stereo Out
1× Monitor Out
1× Headphone Out
4× Aux Out
4× Group Out

Mix Routing

Stereo Main / 1× Stereo Bus / 4× AUX / 4× GROUP

Built-In Effects

SPX Algorithm: 24 Programs, PARAMETER Control: 1, FOOT SW: 1 (FX RTN CH on/off)

Wireless

No

Rack Mountable

Yes

Mixer

Pad

26 dB (Mono)

High-Pass Filter (HPF)

80 Hz, 12 dB/oct (Mono/Stereo: MIC only)

Compressor

Threshold: +22 dBu to -8 dBu
Ratio: 1:1 to 4:1
Output Level: 0 dB to 7 dB
Attack Time: ~25 msec
Release Time: ~300 msec

Equalizer

High Gain: ±15 dB @ 10 kHz Shelving
Mid Gain: Mono 250 Hz – 5 kHz Peaking, Stereo 2.5 kHz Peaking ±15 dB
Low Gain: ±15 dB @ 100 Hz Shelving

LED

Peak LED turns on when post EQ signal reaches 3 dB below clipping

Performance

Total Harmonic Distortion (THD)

0.03% @ +14 dBu (20 Hz–20 kHz), GAIN knob: Min
0.005% @ +24 dBu (1 kHz), GAIN knob: Min

Frequency Response

+0.5 dB / -1.5 dB (20 Hz–48 kHz), refer to nominal output level @ 1 kHz, GAIN knob: Min

Equivalent Input Noise

-128 dBu (Mono Input Channel, Rs: 150 Ω, GAIN knob: Max)

Residual Output Noise

-102 dBu (STEREO OUT, STEREO Master Fader: Min)

Crosstalk

-78 dB

Connectivity

Digital I/O

USB: USB Audio Class 2.0 compliant, Max 192 kHz, 24-bit

Power

Power Requirement

AC 100–240 V, 50 / 60 Hz

Power Consumption

30 W

Physical

Dimensions (W × H × D)

17.5 × 5.1 × 19.7" (444 × 130 × 500 mm)

Net Weight

15.0 lb / 6.8 kg

Packaging Info

Package Weight: 20 lb
Box Dimensions (L×W×H): 22 × 20.25 × 8.4"
