Key Specifications

Number of Analog Input Channels

20 (16 Mono / 4 Stereo)

Number of Mic Preamps

16

Analog Output Channels

4× Stereo Master Output
2× Stereo Control Room/Monitor Output
4× Mono Aux Send Output
4× Mono Bus/Subgroup Output

Mix Routing

Stereo, Aux, Bus/Subgroup

Built-In Effects

Yes

USB I/O

1× USB-B 2.0 (2-Track Record, Audio Playback, Host Connection)

Wireless

No

Rack Mountable

Yes

Mixer

Max I/O Capacity

20× Input / 12× Output

Faders & Level Adjustment

16× Channel Fader
2× Bus/Subgroup Fader
1× Master Fader

Meters

Main Meter: 2× 12-Segment LED

Signal Processing

Gain/Trim Range

Line: -6 dB to +38 dB
Mic: +20 dB to +64 dB

Input Pad

-26 dB

Compressor

Yes (on Input Channels)

Equalizer

Mono Channels: 3-Band EQ
High: ±15 dB @ 10 kHz (Shelving)
Mid: ±15 dB @ 250 Hz–5 kHz (Semi-Parametric)
Low: ±15 dB @ 100 Hz (Shelving)

Stereo Channels: 3-Band EQ
High: ±15 dB @ 10 kHz (Shelving)
Mid: ±15 dB @ 2.5 kHz (Bell)
Low: ±15 dB @ 100 Hz (Shelving)

Filters

16× High-Pass Filters (80 Hz)

Solo/Mute

Mute per Input Channel, Bus, FX Bus, Master

Digital Audio

Sample Rates

Up to 192 kHz

Bit Depth

Up to 24-Bit

Performance

Frequency Response

20 Hz–48 kHz (+0.5 / -1.5 dB)

Noise Floor

-102 dBu (Residual Output Noise, Stereo Out)

THD

0.03% @ +14 dBu (20 Hz–20 kHz, Min Gain)
0.005% @ +24 dBu (1 kHz, Min Gain)

Connectivity

Analog Inputs

12× Combo XLR/TRS Mic/Line
4× XLR Mic
4× 1/4" TRS Line (2 Stereo Pairs)
2× RCA Stereo Line (2 Pairs)
1× 1/4" TS Footswitch Input

Analog Outputs

2× XLR Stereo Main
2× 1/4" TRS Stereo Main
2× 1/4" TRS Control Room
4× 1/4" TRS Aux Send
4× 1/4" TRS Bus Output
1× 1/4" TRS Stereo Headphone Output

Phantom Power

+48 V, Selectable On/Off (Applied to All Inputs)

USB I/O Capacity

2× Input / 2× Output

MIDI I/O

No

Compatibility

OS Compatibility

macOS / Windows

Power

AC Input Power

100–240 VAC, 50 / 60 Hz

Physical

Rackmount Size

10U (with Included Hardware)

Dimensions

17.5 × 5.1 × 19.7 in / 44.5 × 13 × 50 cm

Weight

15.7 lb / 7.1 kg

Packaging Info

Package Weight

20.6 lb

Box Dimensions (L×W×H)

22 × 20 × 8.5 in
