Key Specifications

Max I/O Capacity

16x Input / 8x Output

Number of Analog Input Channels

16

Number of Mic Preamps

4

Number of Analog Output Channels

8

Faders & Level Adjustment

12 Fader

Built-In Effects

13x Stereo Effect (Type Unspecified)

Analog Inputs

4x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input
4x 1/4" TRS Balanced/Unbalanced Stereo Line Input
4x RCA Coaxial Stereo Line Input

Analog Outputs

2x XLR Main Output
8x 1/4" Output

USB I/O

2x USB-C

Wireless

No

Rack Mountable

Yes

Mixer

Mix Routing

1x Main LRC, 2x Bus, 1x FX Return

Presets

Yes

Display

4.3" Touchscreen

Meters

12x LED

Signal Processing

Gain/Trim Range

Up to +86 dB

Graphic EQ

Yes

Solo/Mute

Solo, Solo-in-Place/AFL, Mute, PFL per Input Channel

Audio Delay

Yes

Automatic Mic Mixing

Yes

Digital Audio

Sample Rates

Up to 96 kHz

Performance

Frequency Response

20 Hz to 20 kHz (at 1 kHz)

Analog Dynamic Range

125 dB / 115 dB (at Min Gain)

THD

< 0.002% at Min Gain (+4 dBu)

Recording

Max Multitrack Recording

18 Tracks

Media Support

SD, USB Drive

Max Media Storage Capacity

1 GB

Power

Input Power

100 to 240 VDC

Physical

Dimensions

13.2 x 12.5 x 3.8" / 33.5 x 31.8 x 9.7 cm

Weight

8.6 lb / 3.9 kg

Packaging Info

Package Weight

14.83 lb

Box Dimensions (L × W × H)

19.7 x 16.4 x 7.3"
