Key Specifications

Max I/O Capacity

16x Input / 14x Output

Number of Analog Input Channels

16 (8 Mono / 4 Stereo)

Number of Mic Preamps

16

Number of Analog Output Channels

14

Faders & Level Adjustment

16x 2.4" / 60 mm Motorized Channel Fader
16 FX Knob
5 Knob
1 Knob (Touch Sensitive)

Built-In Effects

11x Effect (Type Unspecified)

Analog Inputs

8x Combo XLR-1/4" TRS Balanced Mic/Line Input
4x 1/4" TRS Balanced/Unbalanced Line Input
2x Stereo RCA Coaxial Unbalanced Stereo Line Input

Analog Outputs

2x XLR Output
8x 1/4" Bus Output
4x 1/4" Headphone Output

Digital I/O

No

USB I/O

1x USB-C (Host Connection, Multitrack Record)
1x USB-C (2-Track Record, Audio Playback, Control, External Memory)

Wireless

Bluetooth 5.0 (Built-In)

Rack Mountable

Yes

Mixer

Mix Routing

1x Stereo Main LRC
8x Bus
2x Mono Matrix
1x Stereo FX Return

Groups

No

Display

4.3" LCD Touchscreen

Signal Processing

Gain/Trim Range

0 dB to +86 dB

Dynamic Processing

Compressor, Multi-Band Compressor, Gate

Digital Audio

Sample Rates

44.1 kHz, 96 kHz

Performance

Frequency Response

20 Hz to 20 kHz (+1/-2 dB)

Analog Dynamic Range

Output: 125 dB
Input to Output: 115 dB

Headphone Output Power

100 mW per Channel into 40 Ohms (Max)

Noise Floor

-108 dBu

THD

< 0.002% at Min Gain (+4 dBu)

Connectivity

USB I/O Capacity

18x Input / 18x Output

External Display I/O

2 x HDMI

Recording

Max Multitrack Recording

18 Tracks

Media Support

SDHC

File Format Support

Playback: MP3, WAV
Record: MP3, WAV

Power

Input Power

16 VDC at 2.4 A
100 to 240 VAC, 50 / 60 Hz

Physical

Operating Conditions

32 to 104°F / 0 to 40°C

Dimensions

16.5 x 3.8 x 12.5" / 419.1 x 96.5 x 317.5 mm

Weight

10.8 lb / 4.9 kg

Packaging Info

Package Weight

17.63 lb

Box Dimensions (L × W × H)

22.2 x 16.2 x 7.3"
