Key Specifications

Inputs/Outputs

• Video Input: 1 x HDMI (2.0)
• Video Outputs: 2 x BNC (3G-SDI)
• Other: 1 x USB-C Input
• Audio: Embedded HDMI/SDI

Format Support

• HDMI Input Formats: 1080p, 1080i, 720p, 480i, 576i
• SDI Output Formats: DCI 2K, DCI 2KPsF, 1080p, 1080PsF, 1080i, 720p, 480i, 576i
• Color: 8/10-Bit 4:2:2 RGB, YUV

Standards & Hardware

• Compliance: SMPTE 259M/292M/296M/424M/425M
• HDCP Support: Yes (Version 2.2)
• Tally Light: No
• OS Compatibility: macOS 10.14.15+, Windows 10

Power & Environmental

• Power I/O: 1 x USB-C (4.4 to 5.2 VDC) Input
• Power Consumption: 2 W
• Operating Temp: 32 to 72°F / 0 to 40°C
• Storage Temp: -4 to 140°F / -20 to 60°C
• Operating Humidity: 0 to 90%

Physical

• Dimensions: 3.01 x 1.8 x 0.98" / 76.45 x 45.7 x 24.89 mm
• Weight: 5.29 oz / 150 g
