Key Specifications

Product / Accessory Type

20-Watt Compact Modeling Guitar Combo Amplifier

Amplification & Modeling Engine

TSAC-HD (White-Box) Amp Modeling Algorithm (Analog Response & Realistic Playability/Feedback)

Preset & Patch Capacity

7 Presets with ACTIVE and Pro SCENE Functions & Per-Preset Patch Level Control

Integrated Phrase Looper & Drum Machine

30-Second Phrase Looper with Auto Tempo Detection Drum Machine

Acoustic, Electrical & DSP Performance Specifications

Amplifier Output Power

20 W RMS

Headphone / Earphone Output Power

280 mW + 280 mW (into 33 Ohms Load)

Digital Processing Resolution

32-Bit Processing with 48 kHz Sampling Rate

System Signal Latency

1.42 ms Ultra-Low Latency

Effect Blocks & Signal Chain

8 Reorderable Effect Blocks: GATE, COMP, EFX, AMP, EQ, MOD, DLY, RVB

Speaker Component Specifications

Loudspeaker Transducer

1x 203.20 mm (8.00") Custom Driver (4 Ohms Impedance / 20 W Power Handling)

Input & Output Impedance Specifications

Instrument Input Impedance

1 MΩ (Hi-Z Pedal-Friendly Input)

Auxiliary Input (AUX In) Impedance

9.1 kΩ

Connectivity, Software & Wireless Specifications

USB Connectivity & Functions

USB Type-B (USB Audio Streaming, Firmware Updates & Mighty Editor™ Communication)

Wireless Connectivity & Included Adapter

NBT-1 Bluetooth Module Included (Bluetooth Audio Streaming & Bluetooth MIDI Control)

Control Software Compatibility

Mighty Amp™ Mobile App & Mighty Editor™ Desktop Editing Software

Dimensions & Weight Specifications

Product Dimensions (L×W×H)

380.00 mm x 186.00 mm x 340.00 mm (14.96" x 7.32" x 13.39")

Product Net Weight

6.60 kg (14.55 lbs)
