Key Specifications

Video I/O & Connectivity

• Video Inputs: 1x 12G-SDI
• Video Outputs: 1x 12G-SDI
• Expansion Slot: 1x SFP Slot
• Embedded Audio: 16-Channel (Fiber Input and Output)

Supported Video Formats

• SDI (4:4:4/4:2:2 RGB, YUV)
• DCI 4K: up to 25 fps
• UHD 4K: up to 60 fps
• DCI 2K: up to 25 fps
• HD (1080p, 1080PsF, 1080i): up to 60 fps

Standards & Compatibility

• Video Compliance: SMPTE 259M/292M/296M/297M/424M-B/425M/ST-2081, ITU-R BT.601
• HDCP/HDR Support: No/Not Specified
• OS Compatibility: Windows 10 (64-Bit), macOS 10.15 to 11.1

Power & Physical

• Power I/O: 1x Barrel (6 to 36 VDC) Input
• Power Consumption: 2 W
• Dimensions: 4.33 x 2.32 x 0.9" / 109.98 x 58.93 x 22.86 mm
• Weight: 7.4 oz / 210 g

Environmental

• Operating Temp: 32 to 104°F / 0 to 40°C
• Storage Temp: -4 to 113°F / -20 to 45°C
• Humidity: 0 to 90% non-condensing
